Mechanical corner steadies from AL-KO for caravans with easy mounting and high stability

Product Information

A0004299 - AL-KO Corner Steady 267265 267265

The mechanical corner steadies from AL-KO feature pressed sections, side bracings, strong rolled trapezoidal threaded spindles and thick hot-dip galvanisation. They can be retrofitted to all AL-KO chassis from 1989 production date. The steadies are extended and aligned using a crank, with different cranks optionally available.

Key Features

• Secure positioning and greater stability on any ground
• Easy to install and fit quickly
• Stable pressed sections
• Strong rolled trapezoidal threaded spindles
• Hot-dip galvanisation corrosion protection
• Compatible with AL-KO anti-theft devices
• Optional different cranks available
• Optional Comfort Kit for easier operation

Specifications

• Premium 1250 kg long: 1250 kg capacity, 2500 kg max vehicle weight, 4.95 kg
• Compact 800 kg short: 800 kg capacity, 1600 kg max vehicle weight, 3.4 kg
• Compact 800 kg long: 800 kg capacity, 1600 kg max vehicle weight, 3.6 kg
• Stabilform 1000 kg short: 1000 kg capacity, 2000 kg max vehicle weight, 4.2 kg
• Turning crank: 1 kg
• Mounting rail: 0.5 kg
• Retaining lug: 0.05 kg

Why Choose AL-KO?

AL-KO is a market leader in caravan and motorhome chassis technology, axles, stabilisers and safety systems. With decades of German engineering excellence, AL-KO components are trusted as original equipment by leading caravan and motorhome manufacturers across Europe.
